General Overall Views


	             Left View					    Right View





	        Action Closed					    Action Open





	       Front Left View					  Rear Left View





	      Bottom Front Left				     Closeup of Stacking Rod
			 				               and Bayonet Lug

Points of interest on the above photos.  You can tell that the above rifle was manufactured to 1914 standards in that it has 2 recoil lugs, the original 1892 only had the front, the rear was a later design addition.  Also, it can be seen that the front barrel band has a notch for a cleaning rod but the stock does not have a channel nor does the stock show signs that a previous channel was filled.  This indicates the stock was manufactured after it was decided to remove cleaning rods from the carbines, which once again post dates a standard Mle92.
