General Overall Views




The following are overall views of the rifle and some major components.




	             Left View					    Right View





             Left Side Showing Receiver,			      Top View of Closed Action
           Closed Bolt and Trigger Guard





	     Top, Middle Area View			          Close-up of Rear Site





      Muzzle from Bottom Showing Cleaning	         Closeup of Front Site and Locking Lugs
    Rod, Bayonet Lug and Magazine Tub Cap 	            for Tube Cap, Stock and Front Band

Points of interest on the above photos.  The upper hand guard can be seen indicating that this rifle has had the "Colonial" modification.  The close-up photo of the receiver and trigger guard also shows the cut-off lever, it is currently set for feeding rounds from the tube magazine(parallel to the barrel).  For single shots, the lever is rotated downwards which locks the feed lever into the up position.
